Ball Screw Mechanical Linear Actuator | SEIMITSU

Category: Technology

Ball Screw Ball Screws plays an important role along with its size from miniature to Ultra-large sizes in Industrial sectors like Machine Tools, Moulding Machines, General Machinery and for the possible and special use which comes under environments, semiconductor and LCD production equipment industry. The arrangement of Ball screw is high efficiency feed screw which consists of a screw spindle and nut which are integrated with rolling elements motion between screws axis and the nut and its cycle arrangement through a return mechanism Here ball screw has a balls inside the nut arrangement which used to give maximum moment at lesser power as a result of increase accuracy of the machine. Rolled Ball screw type of Ball Screw: What is Slim Nut Model JPF? Slim nut model JPF Achieves a zero backlash through a constant preloading means put a spacer between two nuts by shifting phase as result of create pressure at both end of nut therefore constant preload method allows; the ball screw to absorb the pitch error and it achieves a smooth linear motion. Rolled ball screw types depend upon for which application is to be used. Demanding in Following industrial application: 1. Automation 2. Automotive 3. Machine tool 4. Pharma Industry 5. FMCG Industry 6. Packaging Industry 7. Aerospace Precaution on Use: 1. As precautionary purpose does not disassemble the parts because it will result in stop functionality of product. 2. While assembling process make sure ball screw nut should be assembled ball screw shaft. 3. Do not use the product at temperature above 80°C or above. 4. Prevent the product from foreign particles like cutting chips and coolant it may cause to failure or damage our product. 5. The ball screw always uses in stringent condition by providing Linear Motion Guide, Ball spline or Other Guide element. 6. Make sure before using the material feed lubricant.
