SVR Global is the leading Pneumatic actuated butterfly valve manufacturer in USA. Our high-quality valves are supplied to the oil and gas, chemical, and mining industries in Alabama, Texas, and California. Pneumatic Actuated Butterfly Valves are renowned for their ability to regulate fluid flow, whether it involves stopping or initiating it. These valves are particularly effective in low-pressure situations and can handle significant volumes of liquid, gas, and even fluids with suspended particles. Their unique feature is the conversion of compressed gas power into mechanical motion, making them highly reliable and efficient in operation. Additionally, these valves are cost-effective when it comes to maintenance. The key components of Pneumatic Actuated Butterfly Valves include the pneumatic actuator, butterfly valve, valve body, stem, disc, and seats. The pneumatic actuator converts air pressure into mechanical motion, enabling the opening and closing of the valve. The butterfly valve is the primary component that controls the flow of fluid or gas through the system. The valve body serves as the main housing, accommodating the butterfly valve and pneumatic actuator. The stem connects the butterfly valve to the pneumatic actuator, facilitating the transfer of motion. The disc, attached to the stem, is a circular plate that rotates to regulate the flow of fluid or gas. The seats are the surfaces against which the disc creates a seal, preventing the passage of fluid or gas through the valve. • Flanges: The flanges are the end connections of the valve body and allow the valve to be bolted to the pipeline. • Positioner: The positioner is a device that senses the position of the valve and provides feedback to the controller. • Solenoid valve: The solenoid valve is a device that controls the flow of air to the pneumatic actuator. • Limit switches: The limit switches are devices that sense the open and closed positions of the valve and provide feedback to the controller. INDUSTRIES • Chemical industry • Oil & gas industry • Petrochemical industry • Technical gases industry • Energy industry • LNG & LPG industry • Textile industry • Petroleum industry Applications: • Chemical processing and manufacturing plants. • Water treatment plants and wastewater treatment facilities. • Oil and gas pipelines and processing plants. • Power generation plants. • Mining and mineral processing. • Pulp and paper processing. • Marine and offshore applications. • Fire protection systems. • Compressed air systems. Advantages: • Precise and reliable flow control. • Fast actuation and response times. • Simple and compact design. • Cost-effective solution for moderate pressures and temperatures. • Easy to install and maintain. • Low maintenance requirements. • Can be used for both on/off and modulating applications. • Can be operated remotely. • Provides high flow rates with low pressure drop. • Can handle high viscosity fluids. SVR Global, the Pneumatic actuated butterfly valve manufacturer in USA manufacture valves with the following description: •Body material: Cast iron, Ductile iron, Stainless steel (SS316, SS304, CF8), Carbon steel, carbon steel, WCB, WCC, WC6, LCB, LCC, LF2, WC9, Duplex steel (F51, F53, 5A, 6A). •Class: 150-300. PN10 – PN40. •Size: 2”-72”. •Connection type: Flanged, Lug type, Wafer type. •Disc: CF8M, SS316L, CF8, Cast iron, Carbon steel, Ductile iron. •Operation: pneumatic actuated. Configuration of a Pneumatic Actuator: Torque – 3 – 9000 nm Operating pressure- 8 Bar Port Connection-NPT1.4” Mounting Base-ISO5211 Temperature–20°C – +80°C Visit our site for more information- https://svrglobal.net/products/pneumatic-actuated-butterfly-valve/
